Key Features:

  • Rugged Enclosure design
  • Customize design
  • Fanless design (low power consumption)
  • Front Panel Optical Bonding
  • Modulize design
  • Anti-glare surface treatment
  • Standard VESA mounting hole support
  • Optional: Sunlight Readable & Touch screen
  • Analog VGA and DVI video inputs
  • The rugged metal housing is designed for use in Military vehicles.

Technical Specification:

Display Sizes: 10.4”, 15”, 19”, 24”, 40 upto 75”
VGA, SVGA, XGA (max. 60 Hz) integrated touch screen, resistive
Resolution: XGA 1024 x 768 pixel (For higher resolution on request)
Type: Wall mount, Console mount, Rackmount & Deck mount
Max Color: up to 16.7 million colours or 256 levels of grey
Viewing angle: +/-85 deg Left/Right & +/-80 deg Up/Down
Contrast : Vary for different sizes of display
Certification: IP65, MIL-STD 810F, MIL-STD 461E Housing rugged aluminum housing
Color : military green (RAL 6031 HR), other colours on request
applications: Radar station Tower control Air traffic control Avionics display

Marine bridge system display C4ISR System Military aerospace display Field traffic control
