Overview: | |
|
ARINC solutions provide feature-rich functionality. Most interfaces offer large transmits and receive message buffer capacity, independently programmable channel bit rates, error injection and detection, and optional IRIG-B receive message time stamping. In addition, our ARINC solutions provide a user-friendly design to the host system with on-board management of message transmission and reception, and graphical application support for monitoring, data logging and simulation for 100% bus loading activity
|
|
|
 |
Key Features:
- Up to 16 Rx and 16 Tx fully compliant ARINC 429 channels
- Error injection/detection
- High performance, high density interface with large buffers
- Advanced, high-level software API included for Windows 7, Vista, XP (32-bit/64-bit) and Linux Kernel
- Supports maximum data throughput on all channels simultaneously
- Independent, software-programmable bit rates for all channels
- Error injection/detection
- Support for 2-wire ARINC 573, 575, and 717
- IRIG-B Receiver/Generator optional
- 16 input and 16 output discretes that handle avionics-level voltages
- On Board Temperature and voltage monitoring
- Easy-to-use BusTools/ARINC Windows-based GUI Bus Analyzer available
- Optional support for LabVIEW and LabVIEW Real-Time
|
| |
FORM FACTORS: XMC
PMC VME VXI USB PXI
PCI/PCI-X PCIe Express card CPCI PXI |
|
|
|
|
|
|
|
|
